B Grade Item
Please note that this is a B Grade clearance item. It will be in good condition, but may show light signs of use and/or have been repackaged. The price has been reduced to reflect this.
All B Grade items are complete, working and have been fully tested.
This item is supplied with a 12 month warranty.
Key Features
- Built in AVR
- DC Cold Start
- Audible Alarm
- USB Connectivity
- Intelligent CPU Control
- Wide Input Range
- Software Monitoring
- Compatible with generators
- Strong EMI compatibility, no EMI to load
- Protection against Surge, Over / Under Voltage
Specifications
Model : | 850VA |
Power (Watts) : | 510W |
Input |
Phase : | Single & GND |
Voltage Range : | 165V - 275V / 82V - 138V |
Frequency : | 50Hz / 60Hz ± 10% |
Output |
Voltage Range : | 110V / 120V / 220V / 230V / 240V ± 10% |
Wave Form : | Sine Wave (Mains) ; Square Wave (Inverter) |
Frequency : | 50Hz / 60Hz ± 1% (Battery Mode) |
Crest Factor : | 3:1 |
Transfer Time : | <= 6ms |
Protection |
Energy Rating : | 320 Joules instantaneous response |
Test Standard : | IEEE 587 Cat. A & B |
LAN : | RJ45 |
Noise Filtering |
EMI / RFI : | Full time suppression |
Communication
USB with Monitoring Software
|
I/O Ports |
UK Mains Socket : | Two |
RJ45 : | Two (In/Out) |
USB Port : | One (For USB Monitoring) |
Battery |
Type : | Sealed Lead-acid maintenance free |
Quantity : | 12V7AH x 1 |
Recharge Time : | 90% capacity after 8 hours |
Backup Time : | 15-20 Minutes (dependant on load) |
General |
Noise : | < 45db (1 metre) |
Temperature : | 0 - 40°C |
Humidity : | 20% - 90% (Non-Condensing) |
Dimensions : | 320 x 96 x 163mm (L x W x H) |
Packaging Dimensions : | 375 x 145 x 230mm (L x W x H) |
Colour : | Black |
Main Features
- Built in AVR
- DC Cold Start
- Audible Alarm
- USB Connectivity
- Intelligent CPU Control
- Wide Input Range
- Software Monitoring
- Compatible with generators
- Strong EMI compatibility, no EMI to load
- Protection against Surge, Over / Under Voltage
