This 4-Port USB DisplayPort KVM Switch combines the next generation of digital display interface standards with seamless KVM control of connected PC or Mac computers. Delivering ideal multi-computer control for demanding high-resolution multimedia applications, or computer environments requiring true high definition capability. This robust KVM switch supports DisplayPort connections with a native resolution of 2560 x 1600 (@60 Hz, 30 bpp), as well as 7.1 HD digital audio (when connected to supporting displays and sources). In addition to offering 7.1 HD digital audio via the DisplayPort connection this four port KVM provides 3.5mm stereo analog audio and microphone switching between the four connected hosts. Suitable for applications that require high quality static imaging, such as medical/health care applications (MRI, X-ray diagnostics etc.), the KVM switch supports a maximum resolution of 3840 x 2400 at a reduced refresh rate.
Main Features
- Fully compatible with Mini-DisplayPort, HDMI, and DVI adaptors
- Supports native DisplayPort computer connections - no adaptor required
- Native resolution: 2560 x 1600 @ 60Hz, beyond 1080p
- Supports a maximum resolution of 3840 x 2400 at lower refresh rates
- VESA and CEA compliant
- 7.1 Channel High Definition Audio support plus dual channel Analog Stereo and Microphone
- Two USB 2.0 peripheral sharing
- No driver or software installation required; Operating system independent
- Hotkey and push-button switching
- Full plug-and-play support with USB keyboards, mice, and connected peripherals
- Platform Independent - Supports Mac and PC operating environments
- Supports DDC2B for monitor detection
- Supports hot-plug, un-plug and link status-failure detection
- User-defined scan time intervals
