StarTech.com Gigabit PoE+ Extender - 802.3at/af - 100m (330ft)

StarTech.com Gigabit PoE+ Extender - 802.3at/af - 100m (330ft)

CCL Code: NET2264

Discontinued

StarTech.com Gigabit PoE+ Extender - 802.3at/af - 100m (330ft)

POEEXT1GAT

Key Features:

  • 2kV ESD and surge protection
  • 52V to 56V input voltage
CCL Code: NET2264

Discontinued

Sorry, this product has been discontinued. We have found some similar products below.

Overview

This Gigabit PoE+ extender spans your Power over Ethernet (PoE) device over longer distances, letting you double the 100m limitations of a traditional PoE infrastructure. Now you can connect your Gigabit PoE device up to a maximum of 200m away, so it's easy to install a remote IP camera or access point. Plus the extender can be daisy-chained for more scalability. Need more distance? This convenient PoE+ repeater maximizes range and flexibility by extending your PoE connection by an extra 100m (330ft), while providing 24-watt power output to compatible devices. Simply connect the extender to your power sourcing equipment (PSE) and your PoE-powered device (PD) and you're all set. The extender is compliant with the 802.3at/af standard, so it will work with existing PSE, such as a StarTech.com PoE+ injector (POEINJ1G) or PoE+ switch (IES81000POE). Still need more distance? If an extra 100m isn't enough, this full-featured PoE extender offers daisy chain capability. You can easily connect four extenders together, letting you install your PoE+ PD up to 500m (1640ft) away. It's perfect for business, education, and retail environments (output wattage is dependent on the number of daisy-chained extenders used). Get up and running quickly. This Gigabit PoE+ extender can be positioned right where you need it, with a wall-mountable design that requires no external power adapter. You can enjoy reliable performance with little worry of downtime or failure, the extender features a rugged metal housing with built-in ESD and surge protection.

Main Features

  • Deploy and access your Gigabit PoE-powered devices (PD) further away
  • Extend your PoE PDs over longer distances by daisy-chaining four extenders up to 500m (1640ft) total range (reduced power output at each connection)
  • Compact, wall-mountable, and rugged metal housing for convenience and reliability
  • 2kV ESD and surge protection
  • Plug-and-play setup with no power adaptor required
  • IEEE 802.3at 30W input to IEEE 802.3at/af 24W output
  • 52V to 56V input voltage
  • Automatically detects your connected PD to prevent damage if incorrectly installed
Specifications

Environmental

Operating Temperature 0 to 50 °C
Operating Humidity 5 to 95 %

Physical

Form Factor Extender
Case Colour Black
In The Box 1 - Gigabit Power over Ethernet Extender • 1 - Instruction Manual
Width 9.4 cm
Depth 7.0 cm
Height 2.6 cm
Weight 0.197 kg

Warranty

Warranty 2 Years Warranty

Key Features

Main Colour Black

Item Details

Manufacturer StarTech.com
Manufacturer Code POEEXT1GAT
UPC 065030860895
Condition New
Warranty

Warranty Information

Warranty 2 Years Warranty

Manufacturer Information

Manufacturer StarTech.com
Manufacturer Code POEEXT1GAT
Q&A

Do you have you a question about the StarTech.com Gigabit PoE+ Extender - 802.3at/af - 100m (330ft)?

Reviews
No reviews have been received for this product yet
Downloads

PDF Datasheets and Manuals

Document File type File size
Manual pdf 0.41MB
Datasheet pdf 0.24MB
