Western Digital AV 500GB SATA II 2.5" Hard Drive - 5400RPM, 16MB Cache

Western Digital AV 500GB SATA II 2.5" Hard Drive - 5400RPM, 16MB Cache

CCL Code: HDD1899

Discontinued

Western Digital AV 500GB SATA II 2.5" Hard Drive - 5400RPM, 16MB Cache

WD5000LUCT

Key Features:

  • 500GB Capacity
  • 5400RPM Spin Speed
  • SATA II Interface
  • 16MB Cache
  • 2.5" Form Factor
  • 3 Year Warranty
CCL Code: HDD1899

Discontinued

Sorry, this product has been discontinued. We have found some similar products below.

Overview

Western Digital WD5000BUCT 500GB (5400rpm) SATA 16MB Cache 2.5 inch Hard Drive.

Main Features

  • 24x7 reliability - These drives are designed to last in always-on streaming digital audio/video environments such as DVR/PVR, digital video surveillance and other demanding multimedia applications
  • Advanced Format Technology - Leading edge technology delivers improved video quality and AV performance through enhanced error correction capability
  • SilkStream technology - Optimized for smooth, continuous digital video playback of up to five simultaneous HD streams. SilkStream is compatible with the ATA streaming command set so AV customers can use standard streaming management and error recovery options
  • Ultra-cool operation - A cool drives is a more reliable drive. WD continues to develop new and innovative ways to keep drives cool while they are operating
  • Quiet - Noise levels have been minimized to less than one sone -- virtually below the threshold of human hearing
  • Low power consumption - The drive draws less than 2 Watts while operating and a mere 4.75 Watts during spin up
  • 1 million hours MTTF (MTBF) - Best-in-class reliability for small-form factor AV storage
  • Pre-emptive Wear Levelling (PWL) - The drive arm frequently sweeps across the disk to reduce uneven wear on the drive surface common to audio video streaming applications
Specifications

Hard Disk

Disk Capacity 500 GB
Drive Capacity 500 GB
Disk Size 2.5 Inches
Drive Size 2.5 Inches
Disk Speed 5400RPM
Interface SATA 3Gb/s
Drive Interface SATA 6Gb/s
Data Buffer/RAM 16 MB

Performance

Data Transfer Rates 3000 MB/s
Mean Time Between Failure (MTBF) 1000000 Hours

Environmental

Operating Temperature 0 to 60 °C
Non Operating Temperature -40 to 65 °C
Shock (Operating) 350Gs for 2ms
Shock (Non Operating) 1000Gs for 2ms
Acoustics (Seek Mode) 25 dB
Acoustics (Idle Mode) 22 dB

Physical

Form Factor Hard Disk Drive
Enclosure type Internal
Width 6.98 cm
Depth 10.02 cm
Height 0.95 cm
Weight 0.10 kg
Barcode 718037787039

Identifiers

Spicers Number 134524
ISPC Code 40363

Warranty

Warranty 3 Year Limited Warranty

Key Features

Interface Type SATA II
Cache Memory 16 MB
Solid State Drive No
Disk Form Factor 2.5"
Interface Type SATA II
Condition New
Intended Use Surveillance
Power Requirement (auto) 10 W
Number of SATA power required 1

Storage

Storage Type HDD

Item Details

Manufacturer Western Digital
Manufacturer Code WD5000LUCT
EAN 0718037787039
Condition New
Warranty

Warranty Information

Warranty 3 Year Limited Warranty

Manufacturer Information

Manufacturer Western Digital
Manufacturer Code WD5000LUCT
Q&A

Do you have you a question about the Western Digital AV-25 500GB Hard Drive?

Reviews
No reviews have been received for this product yet
Downloads

PDF Datasheets and Manuals

Document File type File size
Western Digital WD5000BUCT 500GB (5400rpm) SATA 16MB Cache 2.5 inch Hard Drive pdf 0.32MB
