TP-Link TL-SG105E 5-Port Gigabit Mini Switch

TP-Link TL-SG105E 5-Port Gigabit Mini Switch

CCL Code: NET1978


TP-Link TL-SG105E 5-Port Gigabit Mini Switch


Key Features:

  • 5 x Gigabit Ports
  • Switch Type: Unmanaged
  • Form Factor: Mini
CCL Code: NET1978


Sorry, this product has been discontinued. We have found some similar products below.


What This Product Does

The TL-SG105E 5-Port Gigabit Easy Smart switch is designed specifically for small and medium business networks that require simple network management and basic features.

  • Save up to 75% of power consumption with innovative energy-efficient technology
  • Effectively monitor traffic via Port Mirroring, Loop Prevention, and Cable Diagnostics
  • Keep latency-sensitive traffic moving smoothly and jitter-free with port and tag based QoS
  • Increase network segmentation and security with port-based, tag-based, and MTU

Simple & Effective Management

With the TL-SG105E, you can observe traffic behavior with Port Mirroring, Loop Prevention, and Cable Diagnostics, helping you identify and locate connection problems on your network. Moreover, you can ensure voice and video are always clear, smooth, and lag-free by administrators designating the priority of traffic based on Port Priority and 802.1P Priority. Also, the TL-SG105E supports MTU VLAN, port-based VLAN and 802.1Q-based VLAN functions to improve security and network performance.

Go Green with Your Ethernet

The TL-SG105E features the latest energy-efficient technologies that can greatly expand your network’s capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network. When a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The TL-SG105E can automatically detect the link status of each port and reduce the power consumption of ports that are idle.

Power Budget According to Cable Length

Ideally, shorter cables would use less power with less power degradation over their length; this is not the case with most devices as they will use the same amount of power across the cable regardless of whether it is 10 or 50 meters in length. The TL-SG105E analyzes the length of the Ethernet cable connected and adjusts the power usage accordingly, rather than keeping the power consumption in a conventional solution.

Ease of Use

TL-SG105E is easy to use and manage.

  • Auto MDI/MDI-X crossover on all ports eliminate the need for crossover cables or uplink ports.
  • Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.
  • Rack-mountable but also compact place on desktops with limited space
  • Dynamic LED lights provide real-time work status display and basic fault diagnosis.


Need assistance setting up your TP-LINK device? Our team is here 24/7 to provide toll-free technical support. Whether you bought a TP-LINK product yesterday or years ago, we can help with product setup and configuration at no extra charge. Plus, our 5-year warranty grants you worry-free service for peace of mind.

Key Features

  • 5 10/100/1000Mbps ports provide instant large file transfers
  • Innovative energy-efficient technology reduces power consumption by up to 75%
  • IEEE 802.3x flow control provides reliable data transfers
  • 16K Jumbo frame improves performance of large data transfers
  • Effective network monitoring via Port Mirroring, Loop Prevention and Cable Diagnostics
  • Port and tag-based QoS enable smooth latency-sensitive traffic
  • Abundant VLAN features improve network security via traffic segmentation
  • IGMP Snooping optimizes multicast applications
  • Centrally manage all Easy Smart Switches with Easy Smart Configuration Utility

Package Content

  • TL-SG105E
  • Power Cord
  • Installation Guide
  • Resource CD
  • Rubber Feet

Main Features

  • Provides network monitoring, traffic prioritization and VLAN features
  • Innovative energy-efficient technology reduces power output by up to 75%
  • Simple network set-up on top of plug-and-play connectivity
  • Centrally manage all Easy Smart Switches with Easy Smart Configuration Utility


Buffer Memory 2 MB


Layer 2 Services IGMP Snooping • Link Aggregation • Port Mirroring • Cable Diagnostics • Loop Prevention


MAC Addresses 8,000
Packet Forwarding Rate 7.4M pps
Port Bandwidth 10/100/1000 Mbps


Network Speeds Supported 10/100/1000 MBps
Number of Fixed Ports 5 port(s)
Fixed Port Connector RJ-45
Fixed Port Speed 10/100/1000 Mbps
Fixed Ports/Connectors AUTO Negotiation/AUTO MDI/MDIX


VLANs Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) MTU/Port/Tag VLAN


Standards Compliance FCC, CE, RoHS


Protocols Supported IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p

System Requirements

Operating Systems Supported Microsoft Windows XP/Vista/7/8 • Mac OS • NetWare • UNIX • Linux


AC Voltage Range 100 to 240 V AC
Electrical Frequency 50 to 60 Hz


Operating Temperature 0 to 40 °C
Operating Humidity 10 to 90 %


Form Factor Smart Switch
In The Box TL-SG105E Switch • Power Cord • Installation Guide • Resource CD • Rubber Feet
Width 10.0 cm
Depth 9.80 cm
Height 2.50 cm


ISPC Code 40201
Spicers Number 122405

Key Features

PoE Supported No
Switch Type Unmanaged
Switch Form Factor Mini
LAN Port(s) Speed 10/100/1000
Number of LAN Port(s) 5
PoE+ Supported No


Warranty 1 Year

Item Details

Manufacturer TP-Link
Manufacturer Code TL-SG105E
EAN 6935364022044
UPC 845973022037
Condition New

Warranty Information

Warranty 1 Year

Manufacturer Information

Manufacturer TP-Link
Manufacturer Code TL-SG105E

Do you have you a question about the TP-Link TL-SG105E (5-Port) Gigabit Easy Smart Switch?

Q: Is this the V2.0 version?
Answer by Dan on 15th September 2016
The stock in our warehouse are indeed version 2.0. -Danlevan
0 customers found this answer helpful.
Post Answer
No reviews have been received for this product yet

PDF Datasheets and Manuals

Document File type File size
Manual pdf 4.35MB
Datasheet pdf 1.04MB
