TP-Link TL-SG1008D 8-Port Gigabit Desktop Switch

TP-Link TL-SG1008D 8-Port Gigabit Desktop Switch

CCL Code: NET0355

Sold out

Notify Me

TP-Link TL-SG1008D 8-Port Gigabit Desktop Switch

TL-SG1008D V7

Key Features:

  • 8 x Gigabit Ports
  • Switch Type: Unmanaged
  • Form Factor: Desktop
CCL Code: NET0355

Sold out

Sorry, we don't have any stock of this product. Please click 'Notify Me' and we will let you know when the item is available.

Notify Me
Overview

8-Port Gigabit Desktop Switch

The TP-LINK TL-SG1008D 8-Port Gigabit desktop switch provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Diagnostic LED indicators help you quickly detect and respond to network problems. Adopting lower power consumption design and innovative energy-efficient technology, the TL-SG1008D can save up to 80%1 of the power consumption, making it an eco-friendly solution for your home or office network.

Gigabit Switch

Featured with eight 8 10/100/1000Mbps ports, TL-SG1008D greatly expands your network capacity, enabling instant large files transferring so power users in the home, office, workgroup, or creative production environment can now move larger, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly.

Go Green with Your Ethernet

You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG1008D 8-Port Gigabit Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

Power down Idle Ports

When a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The TL-SG1008D can automatically detect the link status of each port and reduce the power consumption of ports that are idle, resulting in up to an 80% reduction in power use.

Power Budget According to Cable Length

Ideally, shorter cable would use less power because of less power degradation over their length; this is not the case with most devices as they will use the same amount of power across the cable regardless of the length.

Easy to Use

The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminate the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Faster Network Response Times

The non-blocking switching architecture adopted in the Eight-Port Unmanaged Gigabit Desktop Switch greatly improves network response times and significantly speeds up the traffic between subnets by forwarding and filtering packets at full wire speed for maximum throughput.

Diagnostic LED Indicators

The TL-SG1008D features diagnostic LEDs that display link status and activity, enabling you to quickly detect and correct problems on the network.

Universal System Compatibility

The TL-SG1008D is compatible with all 10, 100, and 1,000 Mbps Ethernet devices, allowing you to protect your existing investments while migrating to a faster network.

Industry-Leading Warranty and Support

Industry-Leading2 3-year warranty, 24/7 unlimited technical support

Features

  • Innovative energy-efficient technology saves power up to 80%
  • Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
  • Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
  • 16Gbps Switching Capacity
  • 9K Jumbo frame improves performance of large data transfers
  • Auto-MDI/MDIX eliminates the need for crossover cables
  • Supports MAC address auto-learning and auto-aging
  • Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware
  • Fanless design ensures quiet operation
  • Desktop or wall-mounting design
  • Plug and Play design simplifies installation

Package Content

  • 8-Port Gigabit Desktop Switch
  • Power Adapter
  • User Guide

1 Maximum power savings when compared to a TP-LINK conventional switch, the real saving rate may vary based on the usage condition.

2 Compared to the warranty and tech support that other leading brands of networking and consumer electronics products provide

Main Features

  • 8 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
  • Green Ethernet technology saves the power up to 80%
  • IEEE 802.3x flow control provides reliable data transfer
  • Plastic case, desktop or wall-mounting design
  • Plug and play, no configuration required
Specifications

Memory

Buffer Memory 2 MB

Performance

Backplane 16 Gbps
MAC Addresses 8,000
Packet Forwarding Rate 10 Mbps: 14,880 pps • 100 Mbps: 148,800 pps • 1000 Mbps: 1,488,000 pps
Port Bandwidth 10/100/1000 Mbps

Interfaces/Ports

Full Duplex Capabilities Half/Full Duplex
Number of Fixed Ports 8 port(s)
Fixed Port Connector RJ-45
Fixed Port Speed 10/100/1000 Mbps
Fixed Ports/Connectors Auto-MDI/MDIX

Compliance

Standards Compliance IEEE802.3, 802.3u, 802.3ab, 802.3x
Safety FCC, CE, RoHS

Warranty

Warranty 3 Years.

System

Management Capabilities Green Technology, saving power up to 80% • 802.3X Flow Control, Back Pressure

System Requirements

Operating Systems Supported Microsoft Windows • Linux • Mac OS X

Electrical

AC Voltage Range 100 to 240 V AC
Electrical Frequency 50 to 60 Hz
Power Adaptor Type External

Environmental

Operating Temperature 0 to 40 °C
Operating Humidity 10 to 90 %

Physical

Form Factor Desktop Unit
Case Colour Black
LED Status Indicators Power • Link/Activity
In The Box 8-Port Gigabit Desktop Switch TL-SG1008D V6 • Power Adaptor • Installation Guide
Width 18.0 cm
Depth 9.0 cm
Height 2.55 cm

Key Features

PoE Supported No
Main Colour Black
Switch Type Unmanaged
Switch Form Factor Desktop
LAN Port(s) Speed 10/100/1000
Number of LAN Port(s) 8
PoE+ Supported No

Item Details

Manufacturer TP-Link
Manufacturer Code TL-SG1008D V7
Alternative Part Number TL-SG1008D V6
EAN 6935364020262
Condition New
Warranty

Warranty Information

Warranty 3 Years.

Manufacturer Information

Manufacturer TP-Link
Manufacturer Code TL-SG1008D V7
