Input

• Input Voltage Range: 230 V AC

Output

• Waveform Type: Sinewave
• Output Capacity: 2.2 kVA
• Output Wattage (Maximum): 1.98 kW
• Output Voltage: 230 V AC
• Max Configurable Capacity: 1.98 kVA
• Output Distortion: less than 5 %

Filtering

• Filtering: Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
• Surge Energy: 645 Joules

Display/Warnings

• Audible Alarm: Alarm when on battery : distinctive low battery alarm : configurable delays
• Control Panel: LCD Display

Battery

• Typical backup time at half load: 2.90 minutes
• Typical backup at full load: 4.0 minutes
• Typical Recharge Time: 3 Hours
• Battery Type: Lead acid

Interfaces/Ports

• Input Connection type: British BS1363A IEC-320 C20 Schuko CEE 7/EU1-16P
• Interface Port: 8 x IEC 320 C13 • 2 x IEC 320 C19 • 2 x IEC Jumpers

Environmental

• Operating Temperature: 0 to 40 °C
• Operating Humidity: 0 to 95 %
• Noise Level: 55 dbA

Physical

• Form Factor: 2U Rackmount
• Case Colour: Black
• In The Box: Smart-UPS X • CD with software • Rack Mounting brackets • Smart UPS signalling RS-232 cable • USB cable • User Manual
• Width: 43.2 cm
• Depth: 66.7 cm
• Height: 8.5 cm
• Weight: 37.32 kg

Warranty

• Warranty: 3 years repair or replace (excluding battery) and 2 year for battery,optional on-site warranties available,optional extended warranties available

Identifiers

• Stock Code: UPS0262
• Mfg Code: SMX2200HV
