1TB Kingston FURY Renegade G5 M.2 2280 PCI Express 5.0 x4 NVMe Solid State Drive

Compare

1TB Kingston FURY Renegade G5 M.2 2280 PCI Express 5.0 x4 NVMe Solid State Drive

Name: 1TB Kingston FURY Renegade G5 M.2 2280 PCI Express 5.0 x4 NVMe Solid State Drive
Brand: Kingston
SKU: SSD1887
Price: 179.99 GBP
Availability: InStock

SFYR2S/1T0

£179.99 inc VAT

Available for Free Priority Delivery from Tomorrow

or Click & Collect from Tomorrow

Hurry, only 2 left!

Order within

Buying in bulk? Contact our business team.

Add to Basket

Key Features:

PCIe 5.0 x4 NVMe Interface
M.2 2280 Form Factor
Up to 14.2GB/s Read
Up to 11GB/s Write
4K IOPS Read: 2200K
4K IOPS Write: 2150K

CCL Code: SSD1887

Capacity

Capacity:

Overview

Kingston FURY Renegade G5 PCIe 5.0 NVMe M.2 SSD




View larger		Kingston FURY Renegade G5 PCIe 5.0 NVMe M.2 SSD Unleash the full potential of your system with Kingston FURY Renegade G5 PCIe 5.0 NVMe M.2 SSD. By leveraging the latest PCIe Gen5 x4 controller and 3D TLC NAND, Kingston FURY Renegade G5 SSD offers extreme speeds of up to 14,800/14,000MB/s read/write¹. Optimised for high-performance PCs, gaming PCs and workstations, with full capacities of up to 4096GB², this solution eliminates storage bottlenecks and reduces load times significantly to power high-intensity gaming and video editing, as well as data-heavy workflows. The Kingston FURY Renegade G5 is engineered with a Silicon Motion SM2508 controller based on 6nm lithography and low-power DDR4 DRAM cache for reduced heat and energy consumption. These adaptations ensure smooth operation for demanding applications while preserving efficiency. In addition, its 12-layer PCB design enhances signal quality and data integrity, while keeping performance consistent under heavy workloads. Perfectly balanced for content creation, high-end applications and productivity, this cutting-edge storage solution delivers unmatched speed, efficiency and durability to elevate your gaming and professional experience. Extreme PCIe Gen5 speeds Advanced thermal design Seamless integration Maximised capacity

Take control with cutting-edge PCIe Gen5 x4 speeds of up to 14,800/14,000MB/s¹ read/write and up to 2,200,000/2,200,000 IOPS¹ performance.

Designed with the Silicon Motion SM2508 controller based on 6nm lithography which allows for better thermal management, low-power DDR4 DRAM cache providing less power consumption, independent Buck IC for consistent power draw and a 12-layer PCB for enhanced signal quality and superior data integrity.

Compact M.2 2280 form factor easily slots into most motherboards and is backwards compatible with Gen3 and Gen4 systems.

Full capacities of up to 4096GB² to store your favourite games and media.

Based on “fresh out-of-box performance”, sequential R/W using PCIe 5.0 Ryzen5 7600X CPU and X670E motherboard, random R/W using Intel Ultra7 and Z890 motherboard. Speed may vary due to host hardware, software and usage.
Some of the listed capacity on a flash storage device is used for formatting and other functions and is thus not available for data storage. As such, the actual available capacity for data storage is less than what is listed on the products. For more information, go to Kingston's Flash Memory Guide.

Specifications

Storage

Solid State Capacity	1 TB
Storage Type	SSD
Drive Size	M.2-2280
Memory Type	3D TLC
Drive Capacity	1 TB
Cache Memory	Yes

Performance

Read Speed	Up to 14,200 MB/s
Write Speed	Up to 11,000 MB/s
4K Random Read (AS SSD)	Up to 2.2m IOPS
4K Random Write (AS SSD)	Up to 2.15m IOPS
Data Storage Life	1 PBW
Mean Time Between Failure (MTBF)	2,000,000 hours

Interfaces/Ports

Interface

PCIe Gen5 x4 NVMe

System

Plug and Play

Yes

System Requirements

1 x M.2-2280 slot, supporting PCIe Gen5 x4 NVMe interface

Electrical

Electrical Power Consumption

0.27 ~ 6.6 W

Environmental

Operating Temperature	0 ~ 70 °C
Storage Temperature	-40 ~ +85 °C
Vibration (Operating)	2.17G peak (7 ~ 800Hz)
Vibration (Non-Operating)	20G peak (20 ~ 1000Hz)

Physical

Form Factor	Solid State Drive
Enclosure type	Internal
Case Colour	Black
In The Box	1 x 1TB SSD
Width	22 mm
Depth	80 mm
Height	2.3 mm
Weight	7.3 g

Warranty

5 Years

Key Features

Interface Type	PCI Express 5.0 x4 NVMe
Solid State Drive	Yes
Disk Form Factor	M.2 2280
Read IOPS (4K)	2200 k IOPS
Drive Interface Type	PCIe 5.0 x4 NVMe
Write IOPS (4K)	2150 k IOPS
Intended Use	Desktop
Power Requirement (auto)	5 W
Create Your Own Gaming PC (CCL)	Yes
