Synology RX1217RP 12-Bay Rackmount NAS Enclosure

Synology RX1217RP 12-Bay Rackmount NAS Enclosure

CCL Code: NAS0310

Discontinued

Synology RX1217RP 12-Bay Rackmount NAS Enclosure

RX1217RP

Key Features:

  • Number of Bays: 12
  • Rackmount Form Factor
CCL Code: NAS0310

Discontinued

Sorry, this product has been discontinued. We have found some similar products below.

Overview

Synology Expansion Unit RX1217/RX1217RP delivers an effortless solution for data volume expansion and data backup for Synology 2U RackStation NAS. With additional 12 drive bays, RX1217/RX1217RP seamlessly expands the storage capacity of the connected Synology NAS onthe-fly. Synology RX1217/RX1217RP is backed with Synology's 5-year limited warranty. When drive capacity is running low on a Synology RackStation, Synology RX1217/RX1217RP offers an easy way to immediately expand storage by providing 12 additional drive slots. The RAID volume on the Synology RackStation can be expanded directly without having to reformat the existing hard drives, ensuring service continuity during the expansion process. To ensure 24/7 service uptime, Synology RX1217RP is equipped with redundant power supplies, allowing automatic failover support if one of the PSUs fail. When created as a separate volume, Synology RX1217/RX1217RP also serves as an additional local backup destination for Synology RackStations. Synology RX1217/RX1217RP securely connects to Synology RackStation servers with a high-bandwidth expansion cable, ensuring maximum data throughput and smooth operation - as if they are part of the internal drives of Synology RackStation. SATA 6Gb/s interface ensures the installed drives provide high quality, outstanding data processing performance. Hibernation mode can be manually configured to start automatically when the system has been inactive for a period of time. This not only saves energy but also extends the lifespan of hard drives. RX1217/RX1217RP will also smartly power on/off with the attached RackStation, so no user intervention is needed to keep this system running smartly and efficiently.

Main Features

  • Plug-n-use design for seamless storage space upgrade
  • Online volume expansion on the fly
  • Managed from Synology DiskStation Manager (DSM)
Specifications

Physical

Case Colour Black
Enclosure type Rackmount
In The Box Main Unit X 1 • Accessory Pack X 1 • AC Power Cord X 1 • Expansion Cable: Infiniband X 1 • Quick Installation Guide X 1
Width 43.05 cm
Depth 69.2 cm
Height 8.8 cm
Weight 13.4 kg
Warranty 5 years warranty
Form Factor Rackmount
Pack Quantity 1

Storage

Number of Hard Disks 0
Total Bay Capacity 12 TB
Number of Bays 12

Compatibility

Compatibility RS4017xs+ • RS3617xs+ • RS3614xs+ • RS3413xs+ • RS3618xs • RS3617xs • RS3617RPxs • RS3614(RP)xs • RS3412(RP)xs • RS3411(RP)xs • RS2818RP+ • RS2416(RP)+ • RS2414(RP)+ • RS2212(RP)+ • RS2211(RP)+

Interfaces/Ports

Expansion Port(s) 1 x Infiniband

Compliance

Certifications FCC Class A • CE Class A • BSMI Class A • RoHS

Electrical

Power Supply 2 x 500W
Electrical Voltage 100 to 240 V AC
Electrical Power Consumption 71.32 W
Electrical Frequency 50 to 60 Hz
System Fans 3 x (80mm x 80mm)

Environmental

Operating Temperature 5 to 35 °C
Noise Level (full operating mode) 54.2 dbA
Relative Humidity 5 to 95 %

Item Details

Manufacturer Synology
Manufacturer Code RX1217RP
EAN 4711174722310
Condition New
Warranty

Manufacturer Information

Manufacturer Synology
Manufacturer Code RX1217RP
Reviews
No reviews have been received for this product yet
