Name: Phanteks Eclipse P200A DRGB ITX Case - Black USB 3.0
Brand: Phanteks
SKU: CAS4250
Price: 75.95 GBP
Availability: OutOfStock
Rating: 4.7 (3 reviews)

Phanteks Eclipse P200A DRGB ITX Case - Black USB 3.0

Compare

The Eclipse P200A is a high airflow mini-ITX chassis featuring the Ultra-fine Performance Mesh to bring the highest cooling performance.

Key Features:

PSU not included
0 x 5.25" External Bay(s)
4 x 2.5" Drive(s) Max
0 x 3.5" Drive(s) Max
Max MB Size: ITX
Tempered Glass

CCL Code: CAS4250

Sold out

Sorry, we don't have any stock of this product. Please click 'Notify Me' and we will let you know when the item is available.

Notify Me

Overview

Superb Cooling Flexibility

Front, side and rear radiator options
Supports 240 + 240/280 radiators simultaneously
Up to 7 x 120mm or 2 x 140mm + 5 x 120mm fans
High airflow bottom GPU intake

Uncompromised Feature Set

Supports full-size components
3-Slot vertial GPU ready
Optimal layout for easy installation
Front USB 3.1 Type-C

Ultra-fine Performance Mesh

Increas air intake with enlarged mesh surface area
Seamless front & side panel design with ultra-fine perforations
Maximum airflow performance with integrated dust filter

Integrated D-RGB Lighting

2 x 120mm D-RGB PWM fans included
Software-free D-RGB controller
Optionally sync with motherboard and software

Multiple Storage Options

Space for 4 x 2.5" SSD drives out of the box
Supports up to 4 x 3.5" drives with optional brackets (sold separately)
Maximum storage capacity of 6 drives (2 x 2.5" + 4 x 3.5")

Promotions

Get 5% off components when you buy three or more*

For a limited time, buy at least three different components worth £30 or more from different qualifying categories and get 5% off those items. *Terms & Conditions apply.

Qualifying categories are Processors, Motherboards, Desktop Memory, Solid State Drives, Hard Disk Drives, Power Supplies, CPU Coolers, and Cases.

Promotional Period: From 24th April 2024 till 25th April 2024. 7pm until 8am.

Terms and conditions apply. Click here to view details.

Terms and Conditions

Cannot be combined with any other offer. UK residents only. Offer available on products in qualifying categories. Some items may not be included, such as new product launches - please check the item to ensure the promotion applies. Minimum value of each item must £30 or greater. Discount will apply to three or more items bought from separate categories (e.g. one CPU, one motherboard) in one basket. It will not apply to multiples from categories (e.g. two CPUs). Discount will be applied to the three or more items in your basket - please double-check your basket to ensure the offer applies correctly. Offer does NOT apply to systems that have such components. CCL reserve the right to end this offer at any time. Offer may not be substituted, exchanged, sold, or redeemed for cash or other goods or services. Offer only available on orders placed on CCLonline.com - offer is not available via telephone or our eBay or Amazon stores.

Promotional Period:From 8PM April 27th, 2023 till 2AM April 28th 2023.

Specifications

User Controls

Power Button
Reset Button

Storage

Internal Expansion Bays

4 x 2.5"

Expansion

Expansion Slots

3 x Full Height (Horizontal or Vertical)

Interfaces/Ports

USB Ports	1 x USB 3.1 Type-C 2 x USB 3.0
Headphone Ports	1 x 3.5mm Jack, shared with Microphone
Microphone In Port	1 x 3.5mm Jack, shared with Headphone

Electrical

Cooling System	Front: Supports 2 x 140mm or 120mm fans (2 x 120mm D-RGB fans included) Rear: Supports 1 x 120mm fan Side: Supports 2 x 120mm fans Bottom: Supports 2 x 120mm fans
Power Supply	ATX Power Supply supported

Warranty

5 Years

Physical

Form Factor	ITX Case
Case Colour	Black
Material	Steel Tempered Glass
Motherboard Compatibility	Mini-ITX
In The Box	Eclipse P200A Case 6 x Zip Ties 1 x Vertical GPU Mount 1 x Accessory Bag with necessary screws/standoffs
Width	205 mm
Depth	400 mm
Height	365 mm
Weight	5.5 kg

Key Features

Firewire	No
Max Motherboard Width	170 mm
Max Motherboard Height	170 mm
Main Colour	Black
Case Type	SFF
USB 3.0 Support	Yes
Case Form Factor	ITX
Power Supply Included	No
80Plus Rated	No
PSU Form Factor	ATX
Display Model in Showroom	No
Illuminated	No
e-SATA	No
L.E.D Fan	ARGB
Max 2.5" Drives	4
ATX	No
Micro-ATX	No
ITX	Yes
E-ATX	No
XL-ATX	No
Cooler Height	165 mm
Built-in Card Reader	No
USB Type-C Support	Yes
Front HDMI	No
Side Panel Type	Tempered Glass
GPU Length	355 mm
PSU Depth	190 mm
Front Audio Type	Combined
Number of Fans	2 fan(s)
RGB LED Controller Included	Yes
LED Strip(s) Included	No
Maximum Motherboard Size Supported	ITX
Total 2.5" + 3.5" drive bays	4
Power Requirement (auto)	6 W
USB3.0 ports	2
USB-C ports	1
Low profile expansion	No

Item Details

Manufacturer	Phanteks
Manufacturer Code	PH-EC200ATG_DBK01
EAN	0886523302186
UPC	886523302186
Condition	New

Warranty

Warranty Information

Warranty

5 Years

Manufacturer Information

Manufacturer	Phanteks
Manufacturer Code	PH-EC200ATG_DBK01

Reviews

4.7 / 5 3 reviews

MR T

November 2021

Really good airflow, one if the best ITX cases on the market! It is quite big for ITX but that also makes sure it has the best airflow and ensures temperatures are kept low.

Leslie

September 2021

Really nice case and good price caution required when buying a water cooler , radiator can not be bigger than 273 mm

Ash

May 2021

Great case with side glass panel and two front RGB fans for under 65 good value for what you are getting with this case plus two usb 3.0 and a type c port. Only thing is that the ATX power supply is a the top and power switch is on the top of the case.
