Memory

• Buffer Memory: 1.5 MB

Routing

• Layer 2 Services: MAC Address Table • 16K entries • IGMP Snooping • IGMP v1/v2 Snooping • Supports 256 IGMP groups • Supports at least 64 static multicast addresses • IGMP per VLAN • Supports IGMP Snooping Querier • Loopback Detection • 802.3ad Link Aggregation: • DGS-1210 28/28P/28MP: Maximum of 14 groups/8 ports per group • DGS-1210 52/52MP/52P: Maximum of 26 groups/8 ports per group • DGS-1210 -10/10P: Maximum of 5 groups/8 ports per group • LLDP • LLDP-MED • Jumbo Frame • Up to 9,216 bytes • Spanning Tree Protocol • 802.1D STP • 802.1w RSTP • 802.1s MSTP (for DGS-1210-28MP only) • Flow Control • 802.3x Flow Control • HOL Blocking Prevention • Port Mirroring • One-to-One • Many-to-One • Supports Mirroring for Tx/Rx/Both • Multicast Filtering • Forwards all unregistered groups • Filters all unregistered groups • Configurable MDI/MDIX • MLD snooping v1/v2 (256 groups)
• Layer 3 Services: IP Interface • Supports 1 interface • IPv6 Neighbor Discovery (ND) • Static Routing (for DGS-1210-28MP only) • 64 IPv4 Static Route Entries • 32 IPv4 Static Route Entries

Performance

• MAC Addresses: 16,000
• Packet Forwarding Rate: 41.7M pps
• Stacking Bandwidth (Max): 56 Gbps

Interfaces/Ports

• PoE Supported: Yes
• Power over Ethernet (PoE) Standards: IEEE 802.3af • 802.3at
• Number of Fixed Ports: 24 port(s)
• Fixed Port Connector: RJ-45
• Fixed Port Speed: 10/100/1000 Mbps
• Number of Uplink Ports: 4 port(s)
• Uplink Port Connector: SFP
• Uplink Port Speed: 10/100/1000 Mbps

Wireless

• VLANs: 802.1Q • VLAN Group • Max. 256 static VLAN groups • Configurable VID from 1 - 4094 • Asymmetric VLAN • Auto Voice VLAN • Max. 10 user-defined OUI • Max. 8 default OUI • Auto Surveillance VLAN

Compliance

• Standards Compliance: RFC 783 TFTP • RFC 951 BootP/DHCP Client • RFC 1157 SNMP v1, v2, v3 • RFC 1213 MIB II • RFC 1215 MIB Traps Convention • RFC 1350 TFTP • RFC 1493 Bridge MIB • RFC 1769 SNTP • RFC 1542 BootP/DHCP Client • RFC 1901 SNMP v1, v2, v3 • RFC 1907 SNMP v2 MIB • RFC 1908 SNMP v1, v2, v3 • RFC 2131 BootP/DHCP Client • RFC 2138 RADIUS Authentication • RFC 2139 RADIUS Authentication • RFC 2233 Interface Group MIB • RFC-2246 SSL • RFC 2475 • RFC 2570 SNMP v1, v2, v3 • RFC 2575 SNMP v1, v2, v3 • RFC 2598 CoS • RFC 2618 RADIUS Authentication • RFC 2819 RMON v1 • RFC 2865 RADIUS Authentication • RFC 3164 System Log • RFC 3195 System Log • RFC 3411-17 SNMP • D-Link Private MIB • LLDP MIB • Zone Defense MIB • 2233 Interface Group MIB
• Safety: cUL • CE LVD

System

• Management Capabilities: Web-based GUI • D-Link Network Assistant Utility • Compact CLI • Telnet Server • TFTP Client • Configurable MDI/MDIX • SNMP • Supports v1/v2c/v3 • SNMP Trap • Backup/Upgrade firmware • Smart Wizard • Upload/Download Configuration file • System Log • Max. 500 log entries • BootP/DHCP Client • SNTP • ICMP v6 • IPv4/v6 Dual Stack • DHCP Auto Configuration • Time Setting • SNTP • RMONv1 • Trusted Host
• Certifications: FCC Class A • CE Class A • ICES-003 • VCCI Class A • C-Tick • BSMI
• Security: Broadcast/Multicast/Unicast Storm Control • D-Link Safeguard Engine • DHCP Server Screening • IP-MAC-Port Binding (Smart Binding) • Supports 512 address binding entries • ARP Inspection • ARP + IP Inspection • Supports DHCP Snooping • 802.1X Port-based Access Control • ARP Spoofing Prevention • Max. 64 entries • Traffic Segmentation • SSH v2 • SSL • Supports v1/v2/v3 • Port Security • Supports up to 64 MAC addresses per port • Duplicate address detection

Electrical

• AC Voltage Range: 100 to 240 V AC
• Electrical Frequency: 50 to 60 Hz
• Power Adaptor Type: External

Environmental

• Heat Dissipation: 1552.32 BTUs per Hour
• Operating Temperature: -5 to 50 °C
• Operating Humidity: 0 to 95 %

Physical

• Form Factor: Network Switch
• Case Colour: Black
• Width: 44.0 cm
• Depth: 25.0 cm
• Height: 4.4 cm

Identifiers

• Stock Code: NET3194
• Mfg Code: DGS-1210-28MP
