DLink DES-1024D 24-Port 100 Mbps Desktop Switch

DLink DES-1024D 24-Port 100 Mbps Desktop Switch

CCL Code: NET1092

Discontinued

DLink DES-1024D 24-Port 100 Mbps Desktop Switch

DES-1024D/B

Key Features:

  • 24 x 100 Mbps Ports
  • Switch Type: Managed
  • Form Factor: Desktop
CCL Code: NET1092

Discontinued

Sorry, this product has been discontinued. We have found some similar products below.

Overview

The DES-1024D is an unmanaged 10/100Mbps switch designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands. The switch comes with 24 10/100Mbps ports, allowing a small workgroup to flexibly integrate to Ethernet and Fast Ethernet. These intelligent ports detect the network speed and auto-negotiate between 100BASE-TX and 10BASE-T, as well as between full and half-duplex. All ports support flow control. This function minimizes dropped packets by sending out collision signals when the port's receiving buffer is full.

Main Features

  • 24 10/100Mbps ports
  • Full/half duplex support for each port
  • MDI uplink port for easy expansion
  • Auto-learning of network configuration
  • Flow control in full duplex mode for protection against data loss
  • Back pressure in half duplex mode
  • RAM buffer dynamically allocated for each port
Specifications

Memory

Buffer Memory 0.32 MB

Performance

MAC Addresses 8,000
Packet Forwarding Rate 100 Mbps port: 148,810pps • 10 Mbps port: 14,880 pps
Topology Star

Interfaces/Ports

Network Speeds Supported 10/100 MBps
Full Duplex Capabilities Half or Full on All Ports
Number of Fixed Ports 24 port(s)
Fixed Port Speed 10/100 Mbps
Fixed Ports/Connectors 24 x RJ-45

Compliance

Standards Compliance IEEE 802.3 10BASE-T Ethernet • IEEE 802.3u 100BASE-TX Fast Ethernet • ANSI/IEEE 802.3 NWay auto-negotiation

System

Management Capabilities Unmanaged
Certifications Emission (EMI): FCC Class A, CE Class A, VCCI Class A • Safety: CUL, CB
Ethernet Switching Features IEEE 802.3 10BASE-T Ethernet; IEEE 802.3u 100BASE-TX FAST Ethernet; IEEE 802.3ab 1000BASE-T Gigabit Ethernet; ANSI/IEEE 802.3 NWay Auto-negotiation; IEEE 802.3x Full Duplex Flow Control (Requires server Adaptor to also support Flow Control, for example DFE-550TX)

System Requirements

System Requirements FCC Class A; CE Class A; C-Tick; VCCI Class A; BSMI Class A; UL (UL1950); CSA (CSA950); TUV/GS (EN60950)

Electrical

AC Voltage Range 100 to 240 V AC
Power Consumption 10 W
Electrical Frequency 50 to 60 Hz
Power Adaptor Type Internal

Environmental

Operating Temperature 0 to 40 °C
Operating Humidity 5 to 90 %

Physical

Form Factor Desktop Unit
Case Colour Black / Metalic Grey
LED Status Indicators Per device: Power • Per port: Link/Activity, 100Mbps speed
Width 28.0 cm
Depth 18.0 cm
Height 4.4 cm
Weight 2.8 kg

Key Features

PoE Supported No
Main Colour Black
Switch Type Managed
Switch Form Factor Desktop
LAN Port(s) Speed 10/100
Number of LAN Port(s) 24
PoE+ Supported No

Warranty

Warranty 1 Year

Item Details

Manufacturer DLink
Manufacturer Code DES-1024D/B
UPC 790069246104
Condition New
Warranty

Warranty Information

Warranty 1 Year

Manufacturer Information

Manufacturer DLink
Manufacturer Code DES-1024D/B
