GPU

• Chipset Manufacturer: NVIDIA
• Chipset Model Name: GeForce RTX
• Chipset Model Number: 5080
• Chipset Additional Information: ProArt Edition
• Boost Chip Clock: 2617 MHz
• Graphics Core: CUDA
• Number of Cores: 10,752

Memory

• Memory Size: 16 GB
• Memory Clock: 30 Gbps
• Memory Type: GDDR7
• Memory Width: 256 bit
• Memory Bandwidth: 960 GB/s

Interfaces/Ports

• Video Card Bus Type: PCI Express
• Video Card Bus Version: 5.0 x16
• HDMI Port: 1 x HDMI 2.1b
• DisplayPort: 2 x DisplayPort 2.1b
• 1 x USB-C

Resolution

• Multiple Monitor Support (Max): Yes (4)
• Maximum Resolution: 7680 x 4320

System Requirements

• System Requirements: 1 x PCI Express 5.0 x16 slot

Electrical

• Power Connector: 1 x 12V-2x6 or 3 x 8-pin PCIe
• Power Consumption: 360 W
• Recomended Power Supply: 850 W

Physical

• Form Factor: Graphics Card
• In The Box: Graphics Card
• Speedsetup Manual
• Adapter Cable (1 to 3)
• ProArt GPU Holder
• ASUS Velcro Hook & Loop
• Thank You Card
• Width: 50 mm (2.5 slot)
• Depth: 304 mm
• Height: 126 mm
• Weight: 3 Years

Identifiers

• Stock Code: VGA7540
• Mfg Code: 90YV0N31-M0NA00
