MSI MAG X670E TOMAHAWK WIFI ATX Motherboard for AMD AM5 CPUs

Compare

Key Features:

ATX Form Factor
AMD X670E Chipset
Socket AM5
DDR5 (Max: 192GB / 4 slots)
4 x M.2 & 8 x USB & 4 x SATA
HDMI and Display Port

CCL Code: MBD3498

Sold out

Sorry, we don't have any stock of this product. Please click 'Notify Me' and we will let you know when the item is available.

Notify Me

Overview

MSI MAG AMD AM5 X670E TOMAHAWK Wi-Fi D5 ATX Motherboard

Name: MSI MAG X670E TOMAHAWK WIFI ATX Motherboard for AMD AM5 CPUs
Brand: MSI
SKU: MBD3498
Price: 294.99 GBP
Availability: OutOfStock

Elevate your gaming and computing experience with the MSI MAG AMD AM5 X670E Tomahawk Wi-Fi D5 ATX Motherboard. This motherboard isn't just a component; it's the backbone of your high-performance PC setup, designed to deliver unmatched power and versatility for your AMD AM5 processor.

Elevate your Gameplay

Unleash Your AM5 Processor's Potential:

The MSI MAG X670E Tomahawk Wi-Fi D5 motherboard is engineered to complement your AMD AM5 processor and unlock its full potential. Whether you're a gamer, content creator, or enthusiast, this motherboard offers the performance and features you need.

Built for Gaming and Beyond:

With support for the latest AM5 processors, PCIe 5.0, and DDR5 memory, this motherboard is ready for the future of gaming and computing. Experience faster data transfer speeds and smoother multitasking for a competitive edge.

Integrated Wi-Fi 6E:

Stay connected with the built-in Wi-Fi 6E connectivity. Enjoy lightning-fast wireless speeds and reduced latency for online gaming, streaming, and productivity.

Powerful Functions

Powerful VRM Design:

The motherboard's robust VRM design ensures stable power delivery to your CPU, even during demanding tasks. Overclock with confidence and push your system to its limits.

Mystic Light RGB:

Customise your PC's look with MSI's Mystic Light RGB lighting. Sync your motherboard's lighting with other Mystic Light-compatible components to create a dazzling visual spectacle.

Audio Boost:

Experience immersive audio with Audio Boost technology. High-quality audio components ensure that you hear every detail in your games, movies, and music.

Specifications

CPU

CPU Socket	Socket AM5
CPU Brand	AMD
Installed Processors (Max)	0 (1)
Supported Processor Manufacturer	AMD
64-bit Support	Yes
Socket	AM5

Rear Panel I/O Ports

USB Ports	1 x USB-C 3.2 1 x USB-C 3.1 2 x USB 3.1 4 x USB 3.0
DisplayPorts	1 x DisplayPort 1.4
HDMI Port	1 x HDMI 2.1
RJ-45 Ports	1 x RJ-45
Audio Line In Ports	1 x 3.5mm Jack
Audio Line Out Ports	3 x 3.5mm Jacks
Microphone In Port	1 x 3.5mm Jack
S/PDIF Port	1 x S/PDIF Optical Out
Antenna Connector(s)	2 x SMA Antenna

Internal I/O Connectors

SATA Connectors	4 x SATA III
USB Connectors	1 x USB-C 3.1 header (supports 1 port) 2 x USB 3.0 headers (supports 4 ports) 2 x USB 2.0 headers (supports 4 ports)
Front Panel Connectors	1 x Front Panel 1 x Front Audio
Cooling Fan Support	1 x CPU fan 1 x Pump fan 6 x System fans
TPM Header	1 x TPM header
Power Connector Port	1 x 24-pin ATX 2 x 8-pin EPS
Other Connectors	1 x M.2 slot, Type 2280/22110 (PCIe Gen5) 3 x M.2 slots, Type 2260/2280 (PCIe Gen4) 2 x 3-pin ARGB LED headers 2 x 4-pin RGB LED headers 1 x Tuning Controller header

Memory

Memory Bus Speed	Up to 6000 MHz
Memory Type	DDR5
Maximum RAM	192 GB
Memory Slot	4 x DIMM

Motherboard

Northbridge	X670E
RAID Supported	Yes
RAID Format	RAID 0, 1, 10
SATA Supported	Yes

Expansion

Number of PCI Express Slots

1 x PCI Express 5.0 x16
2 x PCI Express 4.0 x16 (@ x4/x2)
1 x PCI Express 3.0 x1

Graphics Device

Integrated Graphics Supported

Yes

Warranty

3 Years

Sound

Integrated Sound

Realtek ALC1200

Network

Integrated Network	Realtek RTL8125BG
Network Speeds Supported	Up to 2.5 Gbps
Wireless LAN	Yes (Wi-Fi 6E)
Wireless Network Speed	Up to 2.4 Gbps
Bluetooth	Yes
Bluetooth Version	5.3

System

Software Included (may be trial or restricted)	Yes
Drivers	Yes

Physical

Form Factor	ATX Motherboard
In The Box	Motherboard Quick Installation Guide EU Regulatory Notice 2 x SATA Cables 3 x M.2 Clips Cable Stickers Wi-Fi Antenna M.2 Plate Screw
Width	304.8 mm
Length	243.84 mm

Key Features

Wireless Network	Yes
Motherboard Width	244 mm
Motherboard Height	305 mm
mSATA Supported	No
U.2 Supported	No
Main Colour	Black
Memory Channel	Dual
On-board Audio Type	7.1
Number of SATA Ports	4 port(s)
Number of USB Ports	8 port(s)
USB 3.0 Support	Yes
Multi GPU Support	No
VGA Connection	No
DVI Connection	No
HDMI Connection	Yes
DisplayPort Connection	Yes
Motherboard Form Factor	ATX
Motherboard (EPS) Power Connectors	2 x 8-Pin
Motherboard Chipset	AMD X670E
Thunderbolt	No
Motherboard Model	MSI MAG X670E TOMAHAWK WIFI
WiFi Speed	2400 Mbps
USB 3.1 Support	Yes
Internal USB3.0 Header	Yes
M.2 Support	Yes
On-board RGB Control	MSI Mystic Sync
RGB Header Type	3-Pin ARGB
Addressable RGB	Yes
Internal USB Type-C Header	Yes
Power Requirement (auto)	70 W
Max Memory Speed Supported (Non-overclocked)	4800 MHz
Max Memory Speed Supported (overclocked)	6000 MHz
CPU Power Pins (female)	16
Total M.2 Slots	4
Maximum NVMe M.2 ports	4
SATA ports	4
No. of front USB2.0 ports supported	4
No. of front USB3.0 ports supported	4
No. of front USB-C ports supported	1
