Cooler Master MasterBox E300L Mid Tower Case

CCL Code: CAS3443
|
Manufacturer Code: MCB-E300L-KN5N-B02
|
Manufacturer: Cooler Master
Cooler Master MasterBox E300L Mid Tower Case

Key Features:

  • PSU not included
  • 1 x 5.25" External Bay(s)
  • 3 x 2.5", 2 x 3.5" HDD Bay(s)
  • Max MB Size: Micro-ATX

Discontinued

Sorry, this product has been discontinued. We have found some similar products below.

BRUSHED FRONT PANEL

The brushed texture of the front panel adds an elegant element to your workstation or office and is easy to keep clean. The small vent allows air to flow through and cool the system whilst also helping to prevent dust entering the system.

FAN SUPPORT & SECURITY

The front fan mount of the MasterBox E300L can support a single 80mm, 90mm and 120mm fan, and comes pre-installed with a 120mm fan. The rear fan mount is empty but can support a single 80mm or 90mm fan.

Cooler Master E500L Ventilation Options

SIDE PANEL VENTILATION

The perforated side panel allows for additional airflow for direct cooling on the CPU, and also allows light to escape if you're using an LED or RGB system internally.

Clearances

  • Max GPU Length: 363mm
  • Max CPU Cooler Height: 148mm
  • Max PSU Depth: 180mm, or 160mm with an optical drive installed

Main Features

  • Brushed Front Panel
  • Security Lock Anchor
  • Side Panel with Air Vent

User Controls

User Controls Power
Reset

Storage

External Expansion Bays 1 x 5.25 inch
Internal Expansion Bays 3 x 2.5"
2 x 3.5"

Expansion

Expansion Slots 4 x Full Height

Interfaces/Ports

USB Ports 2 x USB 3.0
Headphone Ports 1 x 3.5mm Jack
Microphone In Port 1 x 3.5mm Jack

Electrical

Cooling System Front: Supports 1 x 80mm, 90mm or 120mm fan (120mm fan included)
Rear: Supports 1 x 80mm or 90mm fan
Power Supply ATX Power Supply supported

Physical

Form Factor Mid Tower Case
Case Colour Black with Silver Trim
Material Steel
Plastic
LED Status Indicators Power
HDD Activity
Kensington Lock Slot Yes
Motherboard Compatibility MicroATX
Mini-ITX
Width 180 mm
Depth 448 mm
Height 364 mm

Warranty

Warranty 2 Years

Key Features

Firewire No
Main Colour Silver
Case Type Tower
USB 3.0 Support Yes
Case Form Factor Mid Tower
Power Supply Included No
Optimised for Business
80Plus Rated No
PSU Form Factor ATX
Display Model in Showroom No
e-SATA No
L.E.D Fan No LED
Internal 3.5" Bay 2
External 5.25" Bay 1
Internal 2.5" Bay 3
ATX No
Micro-ATX Yes
ITX No
E-ATX No
XL-ATX No
Cooler Height 148 mm
Built-in Card Reader No
USB Type-C Support No
Front HDMI No
Side Panel Type Solid
GPU Length 353 mm
PSU Depth 160 mm
Front Audio Type Separate
Maximum Motherboard Size Supported Micro-ATX

Item Details

Manufacturer Cooler Master
Manufacturer Code MCB-E300L-KN5N-B02
EAN 4719512071373
UPC 884102043871
Condition New

Warranty Information

Warranty 2 Years

Manufacturer Information

Manufacturer Cooler Master
Manufacturer Code MCB-E300L-KN5N-B02

Do you have you a question about the Cooler Master MasterBox E300L Mid Tower MicroATX Case (Black) with Silver Trim?

PDF Datasheets and Manuals

Document File type File size
Product Sheet pdf
